U811J81CGE C&K switch pushbutton miniature
Hurry Up! Last one left in stock!
click picture to enlarge
Part Number:
U811J81CGE
Manufacturer:C&K
Item ID: 2027003867C&K U811J81CGE spec
- current rating 1: 1.00 a
- voltage rating 1: 120 vac
- current rating 2: 1.00 a
- voltage rating 2: 28 vdc
- power rating: 0.4va 20v max
- mounting type: through hole
- switch function: spdt
- switch circuit: on - none - (on)
- number of positions: 2
- package: bulk
- item per pack: 1
- Width: 0.38 IN, Height: 0.80 IN, Height: 0.76 IN
Item in stock
can ship right now
(number in the box shows required min quantity)
Description
C&K U811J81CGE Miniature Pushbutton Switch. Amp rating 1 A at 120 VAC. 1 A at 28 VDC. Other rating: 0.4VA 20V MAX. SPDT ON - NONE - (ON) switch function. 2 positions.
Snap-in w/frame actuator "J81". No bushing bushing. PC thru-hole terminals "C". Gold over silver contacts "G". Epoxy seal option "E". Momentary switch. Typical applications in computer peripherals, instrumentation and telecommunications equipment. Made in USA.
